Raven SmarTrax Calibration & Operation Manual

P/N 016-9001-022 Rev. D 47
TROUBLESHOOTING
Wheels are jittery while on-line.
The OL Sensitivity setting is too
high.
Decrease the OL Sensitivity setting
in increments of 1, allowing at least
40 seconds between adjustments.
PWM Min values are too high.
Lower PWM Min values until the
front wheels steer very slowly
manually and with minimum
buttons.
System slowly oscillates while on-
line.
The OL Sensitivity setting is too
low.
Increase the OL Sensitivity setting
in increments of 1, allowing at least
40 seconds between adjustments.
PWM Min values are too high.
Lower PWM Min values until the
front wheels steer very slowly
manually and with minimum
buttons.
Machine consistently drives to the
left or right of the guidance line.
The yaw or SPS/WAS sensor is out
of calibration.
• Recalibrate the yaw sensor to
zero while the machine is
stationary.
• Reset the SPS/WAS center
calibration.
The left or right PWM Min value is
too high.
Lower the appropriate PWM Min
value until the front wheels steer
very slowly manually and with
minimum buttons.
The LA Aggressiveness setting is
too low.
Increase the LA Aggressiveness
setting.
The OL Sensitivity setting is too
low.
Increase the OL Sensitivity setting.
Machine consistently skips or
overlaps in the field.
Antenna is position entered in the
field computer does not correlate
with the position on the roof.
Physically re-measure the antenna
height and offset. Adjust the values
in the field computer.
The system disengages when the
auxiliary hydraulic functions
(including boom and pump
functions, raising and lowering an
implement) are operated.
The knob on the pressure release
switch is turned out too far.
Turn the knob on the pressure
switch in, if applicable.
The Disengage setting is too low. Increase the Disengage setting.
Wheels do not turn fast enough in
LA mode.
The LA Aggressiveness setting is
too low.
Increase the LA Aggressiveness
setting.
Steering wheel is difficult to turn
when attempting to disengage
SmarTrax.
The pressure switch knob or
disengage setting is set incorrectly.
Turn the knob out on the pressure
switch and/or decrease the
disengage setting.
Steering wheel is difficult to turn
when attempting to turn the
vehicle while SmarTrax is not
engaged.
Load sense hose connections are
installed incorrectly.
Verify the load sense hoses are
installed correctly on the SmarTrax
valve.
