RG25DH Operation • Service • Maintenance • Parts Manual

Getting to know your machine

Above is an overview of the basic machine components.

They are explained in more detail on the following pages.

1. Operator Presence Control

2. Engine

3. Battery

4. Cutting Wheel

5. Wheels
