Rayco RG25HD - 12404 Curtain Kit - Rev.

RG25DH Operation • Service • Maintenance • Parts Manual
800.392.2686
61
12404 Curtain Kit - Rev.
3
9
8
5
2
7
6
1
2
4
4
ITEM QTY. PART # DESCRIPTION
1 1 12395 REAR,CHIP WELDMENT
2 2 12397 BRKT-MTG, CURTAIN WELD.
3 1 4024 CURTAIN-SIDE FRONT LEFT
4 2 1524 CURTAIN
5 1 2919 CURTAIN-SIDE
6 1 2905 CURTAIN-REAR
7 1 1526 CURTAIN
8 1 1521 CURTAIN
9 1 4023 BUFFER, BELT GUARD
10 1 12781 RETAINER, CURTAIN
11 1 13322 CURTAIN, SUPPORT
