Rayco RG25HD - 4909 Bail Assembly

RG25DH Operation • Service • Maintenance • Parts Manual
800.392.2686
65
4909 Bail Assembly -
ITEM QTY PART # DESCRIPTION
1 2 728014 PIN, CLEVIS
2 1 726101 WASHER, FLAT 1/4”
3 1 724500 NUT 1/4-20
4 3 724101 NUT HD 1/4-20 GR8
5 3 630013 NUT- PUSH 1/4
6 1 630011 SPRING, DEADMAN SWITCH
7 1 4916 TAB, ADJUST
8 1 4907 KILL SWITCH ROD
9 1 728000 PIN, COTTER
10 1 1601 HANDLE, BAIL
1
10
8
5
10
2
9
6
7
3
4
