RG25DH Operation • Service • Maintenance • Parts Manual
800.392.2686
67
ITEM # QTY. PART # DESCRIPTION
1 1 REF WELDMENT FRAME
2 1 3387
BRACKET, ADJ., ENGINE, WELD-
MENT
3 1 722209 BOLT HEX 5/16−18 X 1−1/4 GR5
4 1 724101 NUT HEX 1/4−20 GR8
5 1 726607 WASHER FENDER 1/4 X 1
6 1 726102 WASHER − LOCK, 1/4”
7 1 722101 BOLT HEX 1/4−20 X 1/2 GR8
8 1 3264 SUPPORT, CABLE, WELDMENT
9 2 722331 BOLT CARRIAGE 3/8−16 X 1
10 4 726301 WASHER FLAT 3/8 USS
11 4 724301 NUT HEX 3/8−16 GR8
12 1 10072 CABLE − FORWARD/REVERSE
13 1 3265 LEVER ENGAGE WELDMENT
14 7 726302 WASHER − LOCK 3/8
15 1 0.3301 WELDMENT ROD END
16 1 3181 ROD WELDMENT − TRANS. LOCK
17 1 620003 SPRING − EXTENSION TRANSAXLE
18 1 630004 KNOB − PLASTIC, ROUND 5/16
19 1 722310 BOLT TAP 3/8−16 X 4 GR2
20 1 722337 BOLT CARRIAGE 3/8−16 X 1−1/2
21 1 620001 PULLEY − IDLER
22 1 620002 PULLEY − TRANSMISSION
23 1 620004 TRANSMISSION − HYDROSTATIC
24 1 620000 GEARBOX − MWF
1 610033
GASKET − GEARBOX/TRANS. (NOT
SHOWN)
25 2 630006 KEY − WOODRUFF 1/8 X 1/2
26 3 722303 BOLT − HEX 3/8−16 X 1
27 4 750061 NUT − WHIZ 3/8−16 GR5
28 2 620007 CLAMP − MUFFLER 1−1/2”
1 762584 BELT − AX37 (NOT SHOWN)
29 2 12376 WHEEL − HUB (RT OR LT)
30 2 630005 KEY − WOODRUFF 1/4 X 1−1/8
31 1 3051 SPACER − WHEEL HUB
32 1 610016L WHEEL − TIRE ASSEMBLY 6−12 LH
32A 1 610016R
WHEEL − TIRE ASSEMBLY 6−12
RH
33 8 71074 0 BOLT LUG 1/2−20
34 4 726907 WASHER FLAT 1−14GA
35 2 750325 RING − RETAIN. EXTRA HEAVY 1”
Hydraulic Drive Assembly
