Raycus RFL-C1500H User Manual

Wuhan Raycus Fiber Laser Technologies Co., Ltd
User Guide of 1500W CW laser
4.7 Control mode selection
4.7.1 Control mode wiring diagram
Figure 11 Wiring diagram in RS-232 mode
Note: In the above mode, the upper computer of Raycus should be used to
modify the mode: turn off the external red light control, external light out enable
and external AD, and only keep the modulation mode.
Laser
Control card
AC input/
regulator
RS232 or Ethernet Connector
30
