14 A-Series display - User reference manual
2.1 Introduction
The A-Series Multifunction display combines advanced chart plot-
ting and high definition digital fishfinder technology within a compact
and powerful navigation system.
Your A-Series Multifunction Display comes equipped with a VGA
(640 x 280 pixel) TFT 256 color sunlight viewable display and an
internal high sensitivity GPS module.
A-Series models
• A50 - 5” display, GPS Chartplotter
• A50D - 5” display, GPS Chartplotter/Fishfinder combination
• A57D - 5.7” display, GPS Chartplotter/Fishfinder combination
• A70 - 6.4” display, GPS Chartplotter
• A70D - 6.4” display, GPS Chartplotter/Fishfinder combination
2.2 System overview
Core System
D11355-1
A-Series display
Sonar
transducer
Power IN
81314-1_A Series Reference Guide.book Page 14 Thursday, August 28, 2008 9:23 AM
