Raymarine AUTOHELM ST50 PLUS DEPTH User Manual

ST50 plus Depth Operation and Installation Handbook
Package Contents
The following items are included in the ST50 Plus Depth package:
1. ST50 Pius Depth control head
2. Fixing studs (2 offI
3. Thumb nuts (2 oftI
4. Fitting template
5. Power cable
6. Depth transducer (through hull) with 14m(45ftI of cable
7. Control head cover
8. Operation and Installation handbook
9. Worldwide Setice Cenb-e handbook
10. Warranty document
11. Security code sticker
!
I
!
!
!
/
1
1
!
I
1
I
ST50 plus Depth Operation and Installation Handbook
- DEP,”
-1
6

Raymarine AUTOHELM ST50 PLUS DEPTH Specifications

Power

power supply	10 to 16 V
power consumption	100 mA
illumination levels	3 levels plus off

Operating Environment

temperature range	0 to 70 °C
shallow alarm	10 to 400 feet (3 to 120 metres)
deep alarm	0 to 600 feet (0 to 180 metres)

Weight and Dimensions

dimensions	110x110 mm (4.33x4.33 in)
depth	0 to 600 feet (0 to 180 metres)
minimum depth	3 to 33 feet (1 to 10 metres)
