Raymarine CP370 User Manual

4.4T
ransducerconnections
W
arning:Transducercables
Donotremovethetransducercablewhilsttheproductispoweredon,doingso
cancausespark
s.Ifthetransducercableisaccidentlyremovedwhilsttheproduct
ispoweredon,switchtheproduct'spoweroff,replacethecableandthenswitch
thepowerbackon.
Caution:Donotcuttransducercables
•Cuttingthetransducercableseverelyreducessonarperformance.Ifthecable
iscut,itmustbereplaced,itcannotberepaired.
•CuttingthetransducercablewillvoidthewarrantyandinvalidatetheEuropean
CEmark.
CP370T ransducerconnections
TheCP370isaClearPulse
TM
sonarmoduledesignedforusewithtraditionaltransducers.
Transducersmustbeinstalledinaccordancewiththeinstructionsprovidedwiththetransducer.
Traditionaltransducerconnection
ItemDescription
1
CP370
2
Optionale xtensioncable(partnumberE66010)
3
T ransducer
54

Raymarine CP370 Specifications

General

Humidity	up to 95% non-condensing
Type	Sonar
Sonar Type	Digital
Frequency	50 kHz, 200 kHz
Power Output	600W
Connections	Ethernet, NMEA 2000
Supply Voltage	10-32 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-30°C to +70°C
Power Supply	12 V DC or 24 V DC
Weight	1.5 kg
Transducer Compatibility	Compatible with various Raymarine transducers
