ItemDescription
6ChannelBofcombinedcable
7
ChannelAofcombinedcable
8
Broadbandtransducer
9
Broadbandtransducer
10SpeedandT
emperaturetransducer
T
ransducerpairconnections
T ransducerPairFrequenciesCableChannelACableChannelB
L ow&HighLowfrequencytransducerHighfrequencytransducer
L ow&MediumLowfrequencytransducerMediumfrequencytransducer
Medium&HighMediumfrequencytransducerHighfrequencytransducer
Note:WhenfittingtransducerpairsensurethatchannelAandchannelBofthetransducercable
areconnectedtotherelevanttransducerasshowninthetableabove .
Singlebroadband(singleelement)transducerconnections(withSpeedandT emperature
transducer)
ItemDescription
1
CP470
2
DualSpeedandT emperatureCHIRPtransducercable(partnumberA80345)
3
Cabletocable(A 80328)connection
4
Cabletotransducerconnection
5
SingleB75/B175operationcable(partnumberA 80328)
