8.1Warningsandcautions
Important:Beforeproceeding,ensurethatyouhavereadandunderstoodthewarningsand
cautionsprovidedintheChapter1Importantinformationsectionofthisdocument.
8.2Schematicdiagram
Aschematicdiagramisanessentialpartofplanninganyinstallation.Itisalsousefulforanyfuture
additionsormaintenanceofthesystem.Thediagramshouldinclude:
•Locationofallcomponents.
•Connectors,cabletypes,routesandlengths.
8.3Toolsrequired
Thefollowingtoolsarerequiredforinstallation.
1.Drill
2.13mm(0.5in)and17mm(0.6in)spanner
3.Drillbit(appropriatesizedependentonthicknessandmaterialofmountingsurface)
4.Jigsaw
5.Pozi-drivescrewdriver
6.Densopaste
7.50mm(2in.)Holesaw
