Raymarine CYCLONE - Product Specifications

15.1Technicalspecification
Approvals
Approvals
Certification
USA47CFRPart80
CertificateofApproval
Cyclone:FCCID:PJ5-953LPSSR
CyclonePro:FCCID:PJ5-953MPSSR
CanadaRSS138Iss.1
TechnicalAcceptanceCertificate
Cyclone:IC:4069B-953LPSSR
CyclonePro:IC:4069B-953MPSSR
EuropeanUnion&EFTA
RadioEquipmentDirective2014/53/EU
Self-Declaration
Australia/NewZealand
ACMADeclarationofConformity
Compliancelevel3
Physical(pedestal)
Cyclone(E70620)CyclonePro(E70621)
Dimensions
388mmx360mmx335mm
(totopofantenna)
388mmx360mmx335mm
(totopofantenna)
Weight
16Kg16Kg
Physical(Antenna)
3ft(E70628)4ft(E70629)6ft(E70630)
Length
1031mm1336mm1945mm
Weight
7Kg
9Kg12Kg
Power
Cyclone(E70620)CyclonePro(E70621)
Supplyvoltage(Using
VCM100)
•Nominal:12Vdcor24Vdc
•Minimum:10.2Vdc
•Maximum:31.2Vdc
•Nominal:12Vdcor24Vdc
•Minimum:10.2Vdc
•Maximum:31.2Vdc
Powerconsumption(typical)
70W95W
Powerconsumption(max)
170W195W
Powerconsumption(standby)
28W28W
Maximumrangescale
72Nm96Nm
Bootuptime
40seconds40seconds
Standbytotransmit
Lessthan5secondsLessthan5seconds
Environmental
Cyclone(E70620)CyclonePro(E70621)
Waterproofrating
IPX6IPX6
Operatingtemperaturerange
-25°Cto+55°C(-13°Fto131°F)-25°Cto+55°C(-13°Fto131°F)
Humidity
Upto93%at40°C(104°F)Upto93%at40°C(104°F)
Maximumwindspeed
100Kts100Kts
