Connectors
Cyclone(E70620)CyclonePro(E70621)
Powerconnection
1xPowerconnector1xPowerconnector
Dataconnection
1xRayNetconnector1xRayNetconnector
Range
Range(Nm)
Pulsewidth(ns)
PRF(Khz)
1/16
464.8
1/8
464.8
1/4
464.8
3/8
1924.8
1/2
1924.8
3/4
7504.8
1
10204.8
11/2
12354.8
216754.8
323004.8
4
27104.8
639004.8
839004.8
12176003.6
16236002.4
24350001.6
32470001.2
48790000.82
72,96790000.7
Transmitter
Cyclone(E70620)CyclonePro(E70621)
Transmitterfrequency
9370,9400,9430MHz(User
Selectable)
9370,9400,9430MHz(User
Selectable)
Peakpoweroutput55W
110W
Receiver
Cyclone(E70620)CyclonePro(E70621)
Receivercharacteristic
LinearLinear
Receivernoise
Lessthan5dBLessthan5dB
Antenna
3ft(E70628)4ft(E70629)6ft(E70630)
Beamwidth(vertical)
25°25°25°
Beamwidth
(horizontal)
2.831.99°1.32°
Polarization
HorizontalHorizontalHorizontal
Rotationspeed
12RPM/24RPM/36
RPM/48RPM/60RPM
12RPM/24RPM/36
RPM/48RPM/60RPM
12RPM/24RPM/36
RPM/48RPM/60RPM
Technicalspecification
