6.Removethemountingtemplate.
7.Thepedestalhasatransitcoverfittedovertheopenarray.Thiscovermustbeleftinplaceuntil
theopenarrayantennaisfittedtothepedestal.
8.Insertthestudsnomorethan11mmintotheholesinthepedestalbase,andhand-tighten.If
thesuppliedstudsarenotlongenoughforthemountingsurfacethickness,useM10stainless
steel,gradeA4-70studdingofasuitablelength.
Important:
Ensuretheventsontheundersidearenotblocked.
9.Passaasuitablesteelcableorchainthroughthe20mmeyeboltholes.Oncesecure,liftthe
pedestalandtestitfitscorrectlyinitsfinalmountingposition.
Important:
Ensurethepedestalisorientatedcorrectly.
46
