2 DS400X and DS500X Digital Fishfinders
The DS400/500X employs a very high transmission repetition or “ping” rate
which, along with the digital adaptive high sample rate receiver, ensures that
fish and bottom structure are presented in superb detail and optimal color
allocation. The DS400/500X digital bandwidth adaptation adjusts the
receiver band width dynamically from very wide to very narrow, as required
by the actual water conditions. This provides superior fish and bottom
detection in all water conditions.
Features
• DS500X: 5" Transmissive High Brightness TFT Color LCD
DS400X: 3.5" Transflective Daylight Viewable TFT Color LCD
•¼ VGA 76,800 Pixel Display Resolution
• Patented Digital HDFI Technology
• Hands-Off Adaptive Auto Adjustments
• Dual Frequency 200/50 kHz 500W RMS
• Depth/Temp/Speed transducer included with some models, which can
measure water depth, water temperature and speed
• Speedometer-style digital data screen overlay
• NMEA 0183 compliant
• Easy Bracket or Flush mounting
• Waterproof to IPX7
Figure 1-3: Basic Fishfinder System using the DS400/500X
Transducer
Fishfinder
D6451-1
