Chapter 5: Display Set Up 47
Background Color
When the CLASSIC palette is selected, you can also choose the background
color used. Three colors are available for the sonar display background –
black, white and blue.
You will probably find that you need to change the background color in
different light conditions. For example, a white background is probably
easiest to see in bright sunlight, but a black background may be preferable at
night.
Select from the following:
• WHITE (default)
• BLACK
• BLUE
DATA ITEMS...
Data Items provide regularly-used data in a compact form so that most of the
graphics can still be seen. Each data item can be displayed in a separate data
field or scrolled through a single data field every three seconds.
Select ON or OFF for each item. The default is OFF.
• Speed
Reading from transducer’s paddlewheel.
• Temperature
Reading from transducer’s temperature-sensing thermistor.
• Battery
The boat’s battery voltage.
• Log
Total distance travelled by the boat.
• Trip
Distance travelled since the counter was reset.
• Auto Scroll
Scrolls each data item that has been turned ON one-at-a time in the upper
left corner of the screen every three seconds.
• Analog Gauges
Presents data items that have been turned ON as analog gauges rather than
in digital format.
