Page #15 background image
Chapter 2: Installation 5
Chapter 2: Installation
2.1 Introduction
This chapter provides installation instructions for your DS400/500X.
Note: If you wish to practice using the unit before installation, connect the
power cable and use the simulator mode as described in Chapter 3. For pow-
er, connect a 12VDC power supply, attaching the red wire to positive and the
black wire to negative. See Section 3.3 for details.
2.2 Unpacking and Inspecting the Components
Unpack your system carefully, to prevent damage to the equipment. Save the
carton and packing, in case you need to return a unit for service.
Check that you have all the correct system components. These depend on
your system package, as follows:
:
Table 2-1: Supplied Parts
Item Part No.
One of the following units:
DS400X Digital Fishfinder without Transducer, US version
DS400X Digital Fishfinder without Transducer, CE version
DS500X Digital Fishfinder without Transducer, US version
DS500X Digital Fishfinder without Transducer, CE version
E63061
E63062
E63063
E63064
Sun Cover, DS400X
Sun Cover, DS500X
R69070
R69071
Mounting Bracket, DS400X
Mounting Bracket, DS500X
R69072
R69075
Mounting Bracket Knobs, DS400X, DS500X R69073
Power/NMEA cable R69074
Handbook, DS400/500X 81234
Mounting hardware N/A
