Appendix A: Specifications 69
Appendix A: Specifications
General
CE Conforms to 89/336/EEC (EMC)
Size
DS400X
DS500X
H x W x D, excluding mounting bracket
4.45 x 5.12 x 2.7 in (113 x 130 x 68.6 mm)
5.90 x 6.37 x 3.08 in (150 x 162 x 78.3 mm)
Weight DS400X
DS500X
1 lb (448 g)
1.53 lbs (692g)
Environmental Waterproofing: Submersible to IPX7 standard;
suitable for external mounting
Temp Range - Operating: +14°F to +122°F (-10°C to +50°C)
Temp Range -Storage: +4°F to +158°F (-20°C to +70°C)
Humidity up to 95% at 35°C, non-condensing
Power Input 10.0VDC to 18.0VDC, 13.8 VDC nominal
Consumption - Typical <10W @ 12VDC
Mounting Mounting Bracket or optional Flush Mount
Controls 5 defined keys and trackpad
Display 320 x 240 pixels (¼ VGA) color portrait
Display type
DS400X
DS500X
TFT Color LCD
3.5” (89 mm) diagonal Transflective
5.0”(127 mm) diagonal Transmissive
Interface 7 pin Power/NMEA NMEA 0183 receive and transmit
Connector 7 pin transducer
Sounder
Output Power: Adjustable to 500 watts RMS
Frequency Dual 50 kHz and 200 kHz
Pulse Length 100 µsec to 4 msec
Max. Transmit
Rate
1428 pulses / min. @ 50’ range
Depth 2 to 2000 ft (600 m), approx.(actual performance dependent upon
transducer type and conditions in the water column)
