Raymarine E70024 - e127 MFD User Manual

13.1AISoverview
TheAISfeatureenablesyoutoreceiveinformationbroadcastby
othervessels,andtoaddthesevesselsastargetsinthechart
andradarapplications.
WithanoptionalAISunitconnectedtoyoursystemyoucan:
•DisplaytargetsforanyotherAIS-equippedvessels.
•Displayvoyageinformationbeingbroadcastbythesetargets,
suchastheirposition,course,speedandrate-of-turn.
•Displaybasicordetailedinformationforeachtargetvessel,
includingsafety-criticaltargetdata.
•Setupasafezonearoundyourvessel.
•ViewAISalarmandsafety-relatedmessages.
•AddAIS-equippedfriendsandregularcontactstoa“Buddy
List”
AISinformationisdisplayedintheformofanoverlayinthechart
andradarapplications.Additionaldataisdisplayedinadialog
box,forexample:
0
97°T
11.6kt
1.237 n m
00h 0 4m 33s
1
3
2 4 6 75
D12 22 0-1
ItemDescription
1
Dangeroustarget(ashes).
2
Safezone(denedbydistanceand
/ortime).
3
AIStargetvessel.
4Heading.
5
Directionofturn.
6
COG/SOGvector.
7
Safetycriticaldata.
AIS-equippedvesselsinthesurroundingareaaredisplayed
inthechartorradarapplicationastriangulartargets.Upto
100targetsaredisplayed.Asthevessel’sstatuschanges,the
symbolforthetargetchangesaccordingly.
Vectorscanbedisplayedforeachtarget.Thesevectorsindicate
thevesselsdirectionoftravelandthedistanceitwilltravel
overaspeciedperiodoftime(COG/SOGvector).T argets
displayedwiththeirvectorsarereferredtoas‘activetargets’and
arescaledaccordingtothesizeofthevessel.Thelargerthe
vessel,thelargerthetarget.Youcaneitherdisplayalltargetsor
justdangeroustargets.
HowAISWorks
AISusesdigitalradiosignalstobroadcast‘real-time’information
betweenvesselsandshore-basedstationsviadedicatedVHF
radiofrequencies.Thisinformationisusedtoidentifyandtrack
vesselsinthesurroundingareaandtoprovidefast,automatic
andaccuratecollisionavoidancedata.TheAISfeatures
complementtheradarapplication,asAIScanoperateinradar
blindspotsandcandetectsmallervesselsequippedwithAIS.
Note:Itmaynotbemandatoryforvesselstobettedwith
operationalAISequipment.Therefore,youshouldnotassume
thatyourmultifunctiondisplaywillshowALLvesselsinyour
area.Dueprudenceandjudgementshouldbeexercised.AIS
shouldbeusedtocomplementradar,NOTsubstituteit.
AISSimulatorMode
Raymarinerecommendsthatyouusethesimulatorfunctionto
familiarizeyourselfwiththeAISfeatures.Whenthesimulator
functionisenabled(homescreen>Set-up>SystemSettings
>Simulator),itdisplays20AIStargetswithina25nmrange.
ThesetargetsaredisplayedusingtheappropriateAIStarget's
statussymbol,andmovearoundthescreenasiftheywerereal
targets.
Note:IncomingsafetymessagesareNOTdisplayedwhile
thesimulatorisenabled.
118NewaSeries/NewcSeries/NeweSeries

Raymarine E70024 - e127 MFD Specifications

General

Display Size	12.1 inches
Display Type	LCD
Resolution	1280 x 800 pixels
Chartplotter	Yes
Radar Compatibility	Yes
Sonar Compatibility	Yes
Wi-Fi	Yes
Bluetooth	Yes
Waterproof Rating	IPX6
Video Input	Yes
Touchscreen	Yes
Built-in GPS	Yes
Networking	NMEA 2000
Cartography	Navionics, C-MAP
Operating Temperature	-15°C to 55°C
Storage Temperature	-20°C to 70°C
Dimensions	330 x 210 x 60 mm
Weight	3.2 kg
GPS Receiver	Built-in 50 channel
