4.18Remotecontrolfunctions
R
ange
Buttons
Pair
Select
or
D12051 -2
Arrow buttons
Shortcut button
ButtonApplicationwherefunctionavailable:
Defaultfunctions:Chart
Radar
Fishnder
WeatherHomescreen
Range/zoom.•PressUPorDOWNarrow
formomentaryresponse.
•HoldUPorDOWNarrow
forcontinuousresponse.
Openhomescreen.Shortcut:Hold
Selectapplicationin
homescreen(inleft-to-right,
top-to-bottomorder).
•PressUPorDOWNarrow
formomentaryresponse.
•HoldUPorDOWNarrow
forcontinuousresponse.
Togglemenuitemsand
optionsindialogsand
prompts(inleft-to-right,
top-to-bottomorder).
•PressUPorDOWNarrow
formomentaryresponse.
•HoldUPorDOWNarrow
forcontinuousresponse.
Placewaypointatvessel
position.
Shortcut
Mediaplayercontrol
(requiresaBluetooth
mediaplayerpairedto
themultifunctiondisplay).
•PressUP/DOWNarrow
fornext/previoustrack.
•PressSHORTCUTbutton
forplay/pause.
Customizablefunctions:
Openhomescreen.SHORTCUT
Switchactiveapplication
(onlyavailablewhenmultiple
applicationsaredisplayed).
SHORTCUT
60NewaSeries/NewcSeries/NeweSeries
