18.1Dataapplicationoverview
Thedataapplicationdisplayssystemandinstrumentdataon
yourmultifunctiondisplay.
Thedataapplicationenablesyoutoviewnumericdata
generatedbythesystem.Italsoshowsdatafrominstruments
connectedtoyourmultifunctiondisplayusingtheNMEAor
SeaTalk
ng
protocols.
Selectingdatapages
Youcanscrollthroughpre-conguredandcustomdatapages
usingthetouchscreen.
Fromthedataapplication:
1.T ouchthescreen.
2.Slideyourngerupandletgoofthescreentogotothenext
datapage.
3.Slideyourngerdownandletgoofthescreentogotothe
previousdatapage.
Selectingdatapages
Toselectdatapagesusinganon-touchmultifunctiondisplay
followthestepsbelow.
Fromthedataapplication:
1.MovetheJoystickDowntogotothenextpage,or
2.MovetheJoystickUptogotothepreviouspage.
18.2Pre-congureddatapages
Bydefault,apre-conguredrangeofdataisdisplayedina
numberofdatapages.Eachdatapageconsistsofanumberof
'cells',eachcontainingadifferentitemofdata.
Note:Thedatapagesavailable,bydefaultaredependant
uponthetypeofvesselselectedduringtheinitialsetupwizard
andthenumberofenginesselectedinthedataapplication
menu.
Defaultpagedataitems
Datapagea65/a67/e7/e7D
e95/e97/c95/c97/e125/
e127/c125/c127/e165
Navigation
panel
•COG&SOG
•Heading
•Depth
•CrossTrackerror(XTE)
•Waypoint.GotoInfo
•Trip
•Rollingroad
•COG&SOG
•Heading
•Depth
•WaypointInfo
Environ-
mental
panel
•GWS&GWD
•Pressure
•TrueWindChill
•Set&Drift
•SeaTemperature
•AirTemperature
•GWS&GWD
•Pressure
•TrueWindChill
•AWA&AWS
•Set&Drift
•SeaTemperature
•AirTemperature
•Humidity
Sailing
panel
•COG&SOG
•Heading
•Depth
•AWS&AWA
•VMGWind
•VMGwpt
•COG&SOG
•Compass
•Depth
•Speedthroughwater
•AWS&AWA
•VMGWind
•VMGwpt
•TWS&TWA
Fishing
panel
•COG&SOG
•Heading
•Depth
•Waypoint/GotoInfo
•Set&Drift
•SeaTemperature
•COG&SOG
•Heading
•Depth
•Livewell
•Waypoint/GotoInfo
•Set&Drift
•SeaTemperature
•Localtime
Engine
(Numberof
engines=
1)
•OilPressure
•EngineRPM
•CoolantTemperature
•TotalFuel
•Rudder
•SOG
206NewaSeries/NewcSeries/NeweSeries
