13.6AISstatussymbols
AISstatusisindicatedbyasymbolinthedatabar.
SymbolDescription
AISunitisswitchedonandoperating.
AIScurrentlyunavailable.
AISunitisswitchedoff,ornotconnected.
AISunitisinSilentMode.
AISunitisinSilentMode,withactivealarms.
AISunitisconnectedandswitchedon,but
hasactivealarms.
AISunitisconnectedandswitchedon,but
thedangerousandlostalarmisdisabled.
13.7AISsilentmode
AISsilentmodeenablesyoutodisableAIStransmissions
AISsilentmodeenablesyoutodisablethetransmittingfunctions
ofyourAISequipment.Thisisusefulwhenyoudonotwantto
transmityourvessel’sAISdatatootherAISreceivers,butstill
wishtoreceivedatafromothervessels.
Note:NotallAISequipmentsupportssilentmode.Formore
information,refertothedocumentationthataccompanies
yourAISunit.
EnablinganddisablingAISsilentmodein
thechartapplication
Fromthechartapplication:
1.SelectMenu.
2.SelectAISOptions.
3.SelectAISUnitSet-up.
4.SelectAISSilentMode.
SelectingAISSilentModewillswitchbetweensilentmode
OnandOff.
EnablinganddisablingAISSilentModein
theradarapplication
FromtheRadarapplication:
1.SelectMenu.
2.SelectTrackTargets.
3.SelectAISUnitSet-up.
4.SelectAISSilentMode.
SelectingAISSilentModewillswitchsilentmodeOnandOff.
AISfunction
121

Raymarine E70024 - e127 MFD Specifications

General

Display Size	12.1 inches
Display Type	LCD
Resolution	1280 x 800 pixels
Chartplotter	Yes
Radar Compatibility	Yes
Sonar Compatibility	Yes
Wi-Fi	Yes
Bluetooth	Yes
Waterproof Rating	IPX6
Video Input	Yes
Touchscreen	Yes
Built-in GPS	Yes
Networking	NMEA 2000
Cartography	Navionics, C-MAP
Operating Temperature	-15°C to 55°C
Storage Temperature	-20°C to 70°C
Dimensions	330 x 210 x 60 mm
Weight	3.2 kg
GPS Receiver	Built-in 50 channel
