Raymarine E70024 - e127 MFD User Manual

MenuItemDescriptionOptions
bottomleftcornerof
thescreen:
•DataCell1
•SelectData
Category
•DataCell2
•SelectData
Category
•Off
SelectDataCategory
Allowsselectionofa
datatypebycategory.
DataCell2
•On
•Off
SelectDataCategory
Allowsselectionofa
datatypebycategory.
17.16Depthanddistancewiththe
shnder
Theshnderdisplayprovidesanumberoffeaturestohelpyou
determinedepthsanddistances.Thesefeaturesareillustrated
anddescribedinmoredetailbelow:
D12 22 2-2
1 2 43 5 6 7
Ite-
mDescription
1
Depthreading—currentdepthofseabed.
2DepthTargetID—depthsaredisplayedagainstrecognized
targets.ThesensitivityoftheseIDsisdirectlylinkedtotheFish
Alarmsensitivity;thegreatertheshalarmsensitivity,thegreater
thenumberoflabelledreturns.
3Depthlines—horizontaldashedlinesdrawnatregularintervalsto
indicatethedepthfromthesurface.
4
HorizontalVRMmarker—indicatesthedepthofthetarget.
5
VerticalVRMmarker—indicatesthedistancebehindyourvessel.
6
CursorDepth—thisisthedepthofthecursorposition.
7
Depthmarkers—thesenumbersindicatedepth.
MeasuringdepthanddistancewithVRM
YoucanuseaVariableRangeMarker(VRM)todeterminean
object'sdepthanddistancebehindyourvessel.Thesemarkers
consistofahorizontal(depth)lineandavertical(distance)line,
eachofwhicharelabelledwiththeappropriatemeasurement.
Fromtheshnderapplication:
1.SelectMenu
2.SelectScrollsothatPauseishighlighted(Thismaymakeit
easiertopositionthemarker).
SelectingScrollwillswitchthescrollbetweenPauseand
Resume.
3.Opentheshndercontextmenu.
4.SelectPlaceMarker.
5.Selectthelocationyouwanttoplacethemarker.
Note:Onceplacedyoucanmovethemarkerbyselecting
MoveMarkerfromtheshndercontextmenu.
Fishndermarkercontextmenu
Theshndermarkerincludesacontextmenuwhichprovides
markerinformationandmenuitems.
198NewaSeries/NewcSeries/NeweSeries

Raymarine E70024 - e127 MFD Specifications

General

Display Size	12.1 inches
Display Type	LCD
Resolution	1280 x 800 pixels
Chartplotter	Yes
Radar Compatibility	Yes
Sonar Compatibility	Yes
Wi-Fi	Yes
Bluetooth	Yes
Waterproof Rating	IPX6
Video Input	Yes
Touchscreen	Yes
Built-in GPS	Yes
Networking	NMEA 2000
Cartography	Navionics, C-MAP
Operating Temperature	-15°C to 55°C
Storage Temperature	-20°C to 70°C
Dimensions	330 x 210 x 60 mm
Weight	3.2 kg
GPS Receiver	Built-in 50 channel
