•TheDirectionalcontrolscanbeusedtoscroll
throughtheavailablemenuoptions.
•PressingtheOkbuttonselectsthehighlighted
optionorconrmsanddismissespopup
messages.
•pressingtheBackbuttonreturnstotheprevious
menuorclosesthemenu.
Placingawaypoint
DisplayswithaGPS/GNSSreceivercanuse
waypointstomarkpointsofinterest.
1.UsetheDirectionalcontrolstohighlightthe
desiredlocationwiththecursor.
2.PresstheOKbutton.
Thecontextmenuisdisplayed.
3.SelectPlaceWaypoint.
Aconrmationpopupmessageisdisplayed.
4.SelectOktoplacethewaypoint,orEdittoedit
thewaypointdetails.
Awaypointisplacedatthecursor’slocation.
Contextmenu
AcontextmenuisavailableondisplayswithaGPS/
GNSSreceiver,whichprovidesdataandshortcuts
tomenuitems.
Thecontextmenuprovidesthepositionofthecursor:
•Depth
•Range
Thecontextmenualsoprovidesthefollowingmenu
items:
•PlaceWaypoint
Accessingthecontextmenu
Youcanaccessthecontextmenubyfollowingthe
stepsbelow.
1.UsetheDirectionalcontrolstohighlightan
objectorarea.
2.PresstheOKbutton.
Thecontextmenuisdisplayed.
8.5Zoom
TheZoomfunctiondisplaysmoredetailonscreenby
magnifyingaspecicareaoftheimage.
WhenusingZoomthescreenissplitanddisplays
thezoomedimagealongsidethestandardimage.
Sonarapplication
DownVisionapplication
Thisenablesyouto:
•selectanareafromthestandardviewthatis
magniedanddisplayedalongside.
•increaseanddecreasethezoomlevel.
Thezoomedsectionisindicatedonthestandard
screenbythezoombox.
AdjustingtheZoomlevel
ToadjusttheZoomlevelandareafollowthesteps
below.
Withthestandardviewdisplayed:
1.Pressingthe+buttontoenableZoommode.
2.Subsequentpressesofthe+buttonwillincrease
theZoomlevel
3.Pressingthe–buttonwilldecreasetheZoom
levelandnallyreverttothestandardview.
SelectingaZoomarea
WhenusingZoomtheareadisplayedinthe
magniedareaofthescreencanbechanged.
WithZoomenabled:
1.UsetheUpandDownDirectionalcontrolsto
movethemagniedareaupanddownthrough
thewatercolumn.
Fishnderapplications
