•Airtrappedunderthefrontofthevesselcantravelunderthehullandappearasaerationaft.
Note:
Optimumtransducerlocationwillvarydependingonvesseltype
.Optimumtransducerheightand
angleshouldbeobtainedbytestingthetransducerwiththevesselinthewater.
EMCinstallationguidelines
R
aymarineequipmentandaccessoriesconformtotheappropriateElectromagneticCompatibility
(EMC)regulations,tominimizeelectromagneticinterferencebetweenequipmentandminimizethe
effectsuchinterferencecouldhaveontheperformanceofyoursystem
CorrectinstallationisrequiredtoensurethatEMCperformanceisnotcompromised.
Note:Inareasofe xtremeEMCinterference,someslightinterferencemaybenoticedonthe
product.Wherethisoccurstheproductandthesourceoftheinterferenceshouldbeseparated
byagreaterdistance.
ForoptimumEMCperformancewerecommendthatwhereverpossible:
•R aymarineequipmentandcablesconnectedtoitare:
–Atleast1m(3.3ft)fromanyequipmenttransmittingorcablescarryingradiosignalse.g.VHF
radios,cablesandantennas.InthecaseofSSBradios,thedistanceshouldbeincreasedto2
m(6.6ft).
–Morethan2m(6.6ft)fromthepathofaradarbeam.Aradarbeamcannormallybeassumedto
spread20degreesaboveandbelowtheradiatingelement.
•Theproductissuppliedfromaseparatebatteryfromthatusedforenginestart.Thisisimportant
topreventerraticbehavioranddatalosswhichcanoccuriftheenginestartdoesnothavea
separatebattery.
•Raymarinespecifiedcablesareused.
•Cablesarenotcutorextended,unlessdoingsoisdetailedintheinstallationmanual.
Note:
Whereconstraintsontheinstallationpreventanyoftheaboverecommendations,alwaysensure
themaximumpossibleseparationbetweendifferentitemsofelectricalequipment,toprovidethe
bestconditionsforEMCperformancethroughouttheinstallation.
HV-100productdimensions
A
224.99mm(8.86in)
B
76.00mm(2.99in)
C
112.69mm(4.44in)
20
