i.L
oosenthemountingbolttoadjustthetransducerangle.
Angleadjustment
ii.Loosenthe2mountingbracketscrewstoadjustthetransducerheight.
Heightadjustment
iii.Re-tightenthemountingboltandmountingscrewsbeforere-testing.
Note:
•Itmaybenecessarytomak eseveraladjustmentstothetransducerbeforeobtainingoptimum
performance.
•Itmaynotalwaysbepossibletoobtaindepthreadingsathigherspeedsduetoairbubbles
passingunderthetransducer.
•Ifthetransducerrequiresrepositioningensurealloldholesarefilledwithmarinegradesealant.
