Raymarine HYPERVISIONT HV-300 Series - Page 24

ItemDescription
1R
ed
Port-sidesplit-pairtransducercable
2Green
S
tarboard-sidesplit-pairtransducercable
ItemDescription
1
V esselbowarrowontopfaceoftransducer
2
Elementangleorside:
(port,“P”;starboard,“S”)
Single(all-in-one)transducersaremark ed“0°”
3
V esselbowarrowontopfaceofFairingblockidentifier(directiontovesselbow)
–choosemountingpositionsthataresymmetricaboutthecenterlineofthevessel.
–choosemountingpositionsthatareatleast300mm(12inches)belowthewaterline .
•Transducersshouldbeinstalledinalocationwherethereissufficientclearanceinsidethehullto
fitthenutandhaveatleast100mm(4in)ofheadroomtoallowforwithdrawal.
Coredfiberglasshullmounting
Itisrecommendedthatthetransducerismountedinanon-coredsection,ifinstallationinacored
sectionisrequiredthentheareaaroundtheholemustbeadequatelystrengthenedtoensureitis
notdamagedwhentighteningthehullandanti-rotationnuts.
Important:Installationinacoredfiberglasshullshouldonlybecarriedoutbyacompetent
marineinstaller .
