Productdimensions
A
30 .00mm(1.18in)
G
63.47mm(2.50in)
B
8.00mm(0 .31in)
H
55.00mm(2.17in)
C
85.00mm(3.35in)
I
71.88mm(2.83in)
D
148.48mm(5.85in)
J
63.60mm(2.50in)
E
220 .36mm(8.68in)
K
267.00mm(10.51in)
F
59 .00mm(2.32in)
T ransducercablelength
Thelengthofthecablefittedtothetransduceris:
•HV-300TH—6m(19.69ft).
•HV-300THP-SandHV-300THP-P—2m(6.5ft).
•A4m(13.12ft)HyperVision™transducerextensioncable(A80562)isavailable.
•Itisrecommendedthatamaximumofonecableextensionisused.
Note:
Whenorderingthesplitpairtransducersystempack(T70448)a0 .3m(0.98ft.)‘Y’splittercable
(A80605)anda4m(13.12ft)extensioncable(A80562)arealsosupplied.
Nutsizes
•Hullnut—44mm(1. 73in)acrossflats
•Anti-rotationnut—13mm(0.51in.)acrossflats
Installation25
