5.Ensurethatthecutwillbemadewithintheacceptablecuttingareaofthefairing.
Acceptablecuttingarea
Important:
Onlycutintheareashowncoloredintheaboveillustration.DoNO Tcutinthehatchedareas
shownabove.
6.R echecksteps1to5.
7.Cutthefairingblock.
Bandsawcutting
30
