Appendix 1: Specifications
Display
Keypads
All types
Instrument keypad
Screen
Aspect ratio
Resolution
Viewing angles (max)
6.5” Color VGA TFT-LCD
4:3
640 x 480 pixels
55° from each side, 30° from above, 60° from below
Backlight White LED,
Dimensions
Overall 7.44 in (189 mm) x 6 in (152 mm) x 1.92 in (48.8 mm)
Weight 2 lb (1 kg)
Main power supply
Voltage (working): 10 V to 16 V dc
Voltage (nominal): 12 V dc
Power consumption: Maximum 11 W, standby 3 W
Inrush current (max peak): 1 A
SeaTalk
ng
power supply
Voltage (working): 9 V to 16 V dc
Voltage (nominal): 12 V dc
LEN: 1
Inrush Current (max peak): 1A
Approvals EMC Directive 2004/108/EC
Australian/NZ C-Tick
Power supply (SeaTalk
ng
)
Voltage (working): 9 V to 16 V dc
Voltage (nominal): 12 V dc
Power consumption: Maximum 11 W, standby 3 W
LEN: 2
Inrush current (max peak): 1A
Weight 10.5 oz (300 g)
Approvals EMC Directive 2004/108/EC
Australian/NZ C-Tick
Dimensions (overall) 3.62 in (92 mm) x 5.35 in (136 mm) x 2.24 in (57 mm)
Buttons
Power ( )
CANCEL
MENU
Select Display ( )
PAGE UP
PAGE DN
Rotary Control Rotate to select/adjust
Press in to perform OK function
