Raypak X94 - Page 49

49
CALL
OUT DESCRIPTION 410
M MISCELLANEOUS COMPONENTS
1-M PRV 75 PSI 007223F
2-M T & P Gauge 014647F
3-M Wire Harnesses (All Unit Harnesses) 015467F
4-M Cabinet Harness 015468F
5-M Blower Harness 120V 015469F
6-M Gas Valve Harness 015470F
7-M High Limit / Flow Switch Harness 015471F
8-M Condensate Float Switch Harness 015472F
9-M Control Bezel (Includes Switch Decal) 014886F
10-M Switch/Decal-Membrane 014887F
11-M Control Bezel Cover 014888F
12-M Condensate Trap 015473F
13-M Condensate Float Switch NC 013947F
14-M Condensate Hose 013948F
15-M Condensate Neutralizer (Not Shown) 015199
16-M Insulation Blanket 015474F
17-M Window Combustion Chamber 006947F
18-M Touch-up Paint Cool Dark Gray (Not Shown) 750256
19-M RTV Sealant 2.8 oz. (Not Shown) 008924F
20-M Clear Silicone Sealant 10 oz (Not Shown) 015421F
21-M Plastic Handle 012681F
P PILOT
1-P Igniter Direct Spark 015475F
2-P Igniter Gasket 015476F
3-P Hi Tension Wire 014126F
R REFRACTORY
1-R Refractory (All Panels) 015477F
2-R Refractory Left & Right 015478F
3-R Refractory Front & Rear 015479F
4-R Refractory Top 015480F
S SHEET METAL / CABINET
1-S Jacket To p 015481F
2-S Upper Cabinet Supports 015482F
3-S Vertical Supports 015483F
4-S Heat Transfer Vertical Supports 015484F
5-S Vertical Cabinet Supports 015485F
6-S Flue Collector 015486F
7-S Flue Collector Seal Gasket 015487F
8-S Flue Collector Outlet Gasket 015488F
9-S Flue Exhaust Inlet Collar 015489F
10-S Flue Exhaust Inlet Gasket 015490F
11-S Flue Exhaust Outlet Support Bracket 015491F
12-S Access Panel Intake Air 015521F
13-S Access Panels Inlet/Outlet 015492F
14-S Jacket Control Mounting Panel 015493F
15-S Jacket Front Panel 015494F
16-S Jacket Rear Panel 015495F
17-S Jacket Side Panel Upper Right 015496F
18-S Jacket Side Panel Lower Right 015497F
19-S Jacket Side Panel Left 015498F
VVENTING
1-V Outdoor Vent Termination Tee
PVC Venting 015451
Polypropylene Venting N/A
Stainless Steel Venting 015361
2-V Flue Exhaust Polypropylene Pipe Assy 015507F
3-V Flue Exhaust Adapter 4" (PVC, Polyproplylene, or Stainless Steel) 015508F
4-V Intake Air Filter Box 015520F
5-V Air Filter Media 013290F
CONVERSION KITS* 410
Nat. to Pro. 015502F
Pro. to Nat. 015503F
* Gas conversions are to be done only by a qualified agency.
