Raypak X94 - Installer Setup Record

51
Installer Setup Record
Use this sheet to record Installer Setup Mode settings. This record will simplify setup in
the event it is necessary to Reset Factory Defaults or install a new control. It is also a help-
ful troubleshooting tool, allowing all setup parameters to be viewed on a single page.
Installer Setup Item
Write down or circle the
Installer Setup setting
Default Setting
Celsius or Fahrenheit °C or °F Fahrenheit
Spa Max Temp 104°F
Pool Max Temp 104°F
Pool Fan Mode Eco / Turbo Turbo
Spa Fan Mode Eco / Turbo / Comfort Turbo
Flue Monitor PVC / CPVC/PP / OFF PVC
Max Fan RPM 7500 RPM
Pump Operation
Disabled / 1 Speed / 2 Speed
/ 4 Speed / Variable
Disabled
Spa Heat Speed Disabled
Pool Heat Speed Disabled
Filter Speed Disabled
Freeze Protect Enabled (with Pump Operation)
Valve Operation
Disabled (only available with
pump operation enabled)
Return Valve Position 1 = Pool (if enabled)
Suction Valve Position 1 = Pool (if enabled)
Valve Change Delay Disabled
Aux 1 OFF
Aux 2 OFF
Low Temperature Lockout Enabled
EcoNet Address 16
Control Lockout PIN
