ASCII Programming
MI3 Rev. G Nov/2015 123
0 – no module
2 – 2 channels
4 – 4 channels
(analog outputs)
Presel. Emissivity
Pointer
I = Emissivity from Internal
(by command)
E = Emissivity from
External analog input
(0V - 5V)
D = digital selected FTC1-3
e.g. !HC – no heads
!HC1 2 3 7 8
e.g. !HCR – no heads
!HCR1 2 3 7 8
HCR=0 –> new registration
hex value of Status Code
3
Top temperature value
of output 1
Parameter error BIT3
Register write error BIT4
Analog module error BIT5
Profinet ready BIT6
setting average / peak / valley / advanced hold cancels all other hold modes
setting average / peak / valley / advanced hold cancels all other hold modes
Head Status Codes (read only):
Temperature unit BIT0 // 0 = °C, 1 = °F
Object temperature out of range BIT1 // 1 = out of range
Ambient temperature out of range BIT2 // 1 = out of range
Parameter error for a command BIT3 // 1 = error
Register write error BIT4 // 1 = error
Self-test error BIT5 // 1 = error
Head not connected BIT6 (ab Rev. 2.20, not for Profibus communication boxes)
Ambient temperature compensation BIT7 // 0 = off, 1 = on
Head access error BIT8 (ab Rev. 2.20, not for Profibus communication boxes)
Object temperature out of range BIT9 (ab Rev. 2.20, not for Profibus communication boxes)
Ambient temperature out of range BIT10 (ab Rev. 2.20, not for Profibus communication boxes)
Temperature is over setpoint BIT11 (ab Rev. 2.20, not for Profibus communication boxes)
Self factory default executed BIT12 (ab Rev. 2.20, not for Profibus communication boxes)
for MI3COMM only
