Installation
MI3 Rev. G Nov/2015 33
Figure 18: Terminal Wiring for the Comm Box DIN 6 TE
for Profinet and Modbus
USB Connector, Mini-B
RJ45 connector
Profinet or Ethernet
RELAY
Sensing
Heads
GND
FTC3
8 - 32 V
shield
GND
RELAY
shield
green
white
yellow
brown
shield
green
white
yellow
brown
