RayTek MI3 - USB Connection and Setup

Installation
MI3 Rev. G Nov/2015 37
5.6 USB
The USB interface comes with each box (USB connector, Mini-B). Connect a single unit to a USB
computer port by using an appropriate USB cable.
Figure 21: USB Connection via the Comm Box (metal)
Figure 22: USB Connection via the Comm Box (DIN Rail)
The computer’s USB port
USB connector,
type Mini-B
The computer’s USB port
