Raytheon Anschütz STD 22 Compact GYRO COMPASS User Manual

Operator manual
110--233
STD22 Compact and STD22
2
3646/110 --233.DOC010102 Edition: Sept. 1, 2005
STD 22 Compact as
a stand -alone system
STD22withother
system components
(Distribution Unit and
Operator Unit )
Inputs:
-- GPS positioning data
-- Speed data from the GPS
-- Speed from the Pulse Log
-- Direction of speed from the Pulse Log
-- N M E A
-- 24V d.c. voltage supply
Inputs (via the Distribution Unit
only through a
”CAN bus” data bus system):
-- GPS positioning data
-- Speed data from the GPS
-- Speed from the Pulse Log
-- Leading sign for the speed
from the Pulse Log
-- N M E A
-- 24V d.c. voltage supply
-- DV--bus (no inputs for
speed/position at the
Distribution Unit
Optional feature:
-- Magnetic sonde can be connected
Outputs:
-- 2 x Heading (course bus or NMEA)
designated CHn 1 and CHn 2
-- 1 x Heading (course bus)
-- Status signals
SEC (s
peed error correction)
System
Available
Optional
feature
Additional Output Box 146--103
Input:
-- 1 x Heading (course bus)
Outputs:
SSC--Interface
Step (6 steps/degree)
NMEA 0183 superfast 50Hz
Outputs (at STD 22 compass):
-- 2 x Heading (course bus or NMEA)
-- 1 x Heading (course bus)
-- Status signals
SEC(s
peed error correction)
System
Available
Heading (Course bus or
NMEA) without SEC
Outputs (to the Distribution Unit):
-- 1x RS232 for courseprinter
-- 1x rate of turn
-- 3 x Step (6 steps/degree)
-- 8 x Heading (course bus or NMEA)
12x for version E10
-- D V -- b u s
-- Status signals
Functions:
-- Integral Speed Error Correction (SEC)
Optional feature
-- Quick Settling with the Operator Unit
for Quick Settling
Functions: (Compass STD 22)
-- Integral Speed Error Correction
(SEC)
-- Quick Settling via the operator unit
