Raytheon Anschütz STD 22 Compact GYRO COMPASS User Manual

Operator manual
110--233
STD22 Compact and STD22
12
3646/110 --233.DOC010102 Edition: Feb. 17, 2006
1.3 Technical data
The technical data stated here apply equally to the
STD 22 Compact Gyro Compass and the STD 22 Gyro
Compass
1.3.1 Mechanical data
Gyro compass
Height: approx. 429 mm
Diameter: approx. 414 mm
Weight approx. 16 kg
Type of enclosure: IP23
(see also dimensional drawing 110 D 233 HP005)
1.3.2 Electrical data
Gyro compass
Supply voltage: 18--36 V d.c.
Current consumption: maximum approx. 5A (heating stage)

Raytheon Anschütz STD 22 Compact GYRO COMPASS Specifications

General

Brand	Raytheon Anschütz
Model	STD 22 Compact GYRO COMPASS
Category	Compass
Language	English
