Raytheon Anschütz STD 22 Compact GYRO COMPASS User Manual

Operator manual
110--233
STD22 Compact and STD22
14
3646/110 --233.DOC010102 Edition: May 20, 2005
2 Controls and Indicators on the Gyro Compass
The user information stated here applies equally to the
STD 22 Compact Gyro Compass and the STD 22 Gyro
Compass.
Viewed from above (see Figure 8 )
-- Digital indication of the following:
Compass course
Operating status
Warnings
Error messages
Compass course
or
or
or
Operating status
“heating”
with current temperature
flashing
Warning
Error message
Figure 8 : The indicators on the gyro compass with examples of the type of indication

Raytheon Anschütz STD 22 Compact GYRO COMPASS Specifications

General

Brand	Raytheon Anschütz
Model	STD 22 Compact GYRO COMPASS
Category	Compass
Language	English
