Raytheon Anschütz STD 22 Compact GYRO COMPASS User Manual

Operator manual
110--233
STD22 Compact and STD22
4
3646/110 --233.DOC010102 Edition: May 20, 2005
Quick Settling operator unit (Option)
This function can be used to reduce the time between switching on the compass and
indicating (outputting) a valid course value to one hour (with a precision of +/--3 °).
In the STD 22 Compact this function is activated from the
QS Operator Unit (130-606 NG001); in the STD22 this function is activated from the
Operator Unit (130--613).
The Compact STD 22 gyro compass consists of
-- the 110--233NG001 gyro compass
-- the 111--006 gyrosphere
Optional features:
-- QS Operator Unit, 130 -- 606
-- AC/DC converter, 121--062
-- Additional Output Box,146--103
The Speed Error Correction function is available only when a GPS or Pulse Log is
connected.
The output interfaces
on the STD 22 Compact are as follows:
-- Course (corrected -- SEC) as NMEA or course bus
-- Status signals (alarms, error messages, warnings)
Optional via the Aditional Output Box box:
-- NMEA 0183 superfast (50Hz)
-- Step (6steps/degree)
-- SSC
The input interfaces
on the STD 22 Compact are as follows:
-- NMEA Position
-- NMEA Speed
-- Pulse Log Direction
-- Pulse Log
Status signals or pulses
