Operator manual

Compass

STD 22

110--233

STD22 Compact and STD22

3646/110 --233.DOC010102

Edition: May 20, 2005

1.) Remove the cover of the compass (unfasten the 5 cross--slotted screws)

2.) Move switch B37 (DIP switch), contact (1) to the “OPEN” position.

3. ) The digital indicator is now indicating “ALEr” = Alignment Error

4.) Press button B38 or B39 until the heading you require displays.

As you do so the course value changes (B38 changes the value downwards and

B39 changes it upwards).

If you hold down the button the speed at which it changes will increase.

5.) Move switch B37 (DIP switch), contact (1) back to the “OFF” position.
