Raytheon Anschütz STD 22 Compact GYRO COMPASS User Manual

Operator manual
Compass
STD 22
110--233
STD22 Compact and STD22
37
3646/110 --233.DOC010102
Edition: Feb. 17, 2006
Button B39
Button B38
B37 DIP switch
Display
Button B39
Button B38 B37 DIP switch
Display
E10
Figure 17 :Operating elements on the compass (after removing the cover)
The following failed PC--boards are possible:
PCbP = power PCB faulty
PCbS = sensor PCB faulty
PCBC = connection PCB faulty
PCbG = outer sphere PCB faulty
See the service manual for more details.

Raytheon Anschütz STD 22 Compact GYRO COMPASS Specifications

General

Brand	Raytheon Anschütz
Model	STD 22 Compact GYRO COMPASS
Category	Compass
Language	English
