3.1.1 Interface & Signal
Interface
Descriptions
CON1
DB15 female connector, interface to servo driver.
CON2
Interface for connecting external IO devices.
CON3
Interface to 24V DC power supply.
CON4
Interface for connecting external IO devices.
Pins of CON1：
Pin
Descriptions
1
OUT_Servo_DA（Drive speed command）
2
Servo_TGON（Drive brake signal）
3
Servo_CLR（Drive alarm clear signal）
4
Servo_OS（Drive zero speed clamp, used to control motor lock
shaft）
5
PGND（Power ground）
6
E1_A_N（Encoder A negative）
7
E1_B_N（Encoder B negative）
8
E1_C_N（Encoder C negative）
9
AGND（Analog ground）
10
Servo_ALM（Drive alarm signal）
11
Servo_SON（Drive enable signal）
12
VDD_24V（Power supply）
13
E1_A_P（Encoder A positive）
14
E1_B_P（Encoder B positive）
15
E1_C_P（Encoder C positive）
Pins of CON2：
Pin
Descriptions
N/A
/
N/A
/
Alarm out
When alarm occurs, a high level signal is output, normally is high
impedance state.
Home
Homing input signal, active high.
AGND
Common ground of analog signals, analog signals include: focus set
input, focus feedback output.
Focus set
The input signal of focus setting, is analog.
