DCN 141-01128-04 10/6/08
17
Main Menu - User Settings - Filter Service
The Filter Service screen will show the accumulated Filter Runtime hours as well as the Service Interval
that will be used to trigger a Filter Message. Any type of HVAC operation that causes the HVAC system
fan to run will cause the Filter Runtime value to increase.
When the Runtime hours equals the Service Interval hours, the Red LED will flash along with a “Filter”
message to remind you to replace the filter. Pressing the Menu button will take you to the Filter Service
screen. Once the filter has been replaced, press the Reset button to reset the Filter Runtime value to
zero.
The Service Interval period can be changed using the +/- buttons.
Filter Service Screen
Screen navigation buttons:
Filter Service
Return to Main Menu Screen
Increase the Service Interval by 1 hour
Decrease the Service Interval by 1 hour
Reset the Filter Runtime Timer
Filter Runtime
Service Interval
12 HRS
300 HRS
To Next Page
