Record Power BS250 - Getting To Know Your Bandsaw; Machine Specification

2. Machine Specification
1. Getting To Know Your Bandsaw
Fig.1
A Blade Tensioning Knob
B Rise & Fall Lock
C Blade
D Upper Blade Guide
E Mitre Fence
F Rip Fence
G Rip Fence Rail
H Table
I Stand & Wheel Kit (optional)
J Rise & Fall Knob
K Tracking Knob
L Tracking Knob Lock
M Motor Rating Plate
N Table Tilting Handle
O 100mm Dust Extraction Port
P Motor
6 7
A
B
C
F
I
D
E
H
J
K
P
N
G
L
BS350 SPECIFICATION
Blade length: 1785mm (70
1
/4”)
Blade width: 6mm - 13mm (
1
/
4
” -
1
/
2
”)
Max depth of cut: 120mm
Throat depth: 240mm
Table size: 315 x 350mm
Max width blade to rip fence: 140mm
Table height (from floor): 370mm
Extraction port: 100mm
Motor power (output):
1
/3hp
Weight: 30kg
Footprint: 340 x 240mm
Dimensions: 860mm (height) x 550mm
(width) x 480mm (depth) (without stand)
BS250 SPECIFICATION
M
O
