Record Power BS350 - Fitting the Bandsaw to the Stand

12
3. Stand & Wheel Kit Assembly
3.4 Fitting the bandsaw to the stand
CAUTION! The machine is heavy.
Additional help or a suitable lifting
device or support will be required for
lifting the machine onto the stand.
1. Lift the bandsaw over the stand. and place
the long fixing bolts through the four location
holes in the bandsaw base Fig.3.11.
2. Secure the bandsaw to the stand with the
remaining washers and nuts Fig.3.12.
Fig.3.10
Fig.3.12
Fig.3.11
LONG FIXING BOLTS
1. Feed the long fixing bolts up through the
stand and secure the four corners using the
washers and bolts provided Fig.3.10. Once
this is achieved the whole stand can be fully
tightened ready for the bandsaw to be fitted.
LOCATION
HOLES
200mm 17º
WARNING! For your safety only use the
handle to pull the machine. It is unsafe
to push the machine using the handle.
When lifting the stand ensure the front
legs are not raised higher than 200 mm
from the ground (or at an angle of more
than 17º). Fig.3.13.
Ensure the bandsaw is fitted to the stand
so that the wheels are at the rear (spine
end) of the machine.
Fig.3.13
