Record Power BS350 - Page 38

38
Fig.15.11
Fig.15.2
FLATTENED AREAS
Fig.15.3
RELEASE
CATCH
Fig.15.4
Fig.15.10
RELEASE CATCH
PEDAL
OPERATING FRAME
Fig.15.9
Fig.15.8
REAR OF BANDSAW
Fig.15.6
FIXING PIN
Fig.15.5
AXLE
BRACE SUPPORT BAR
Fig.15.7
AXLE
FIXING PIN
PEDAL
15. Assembly of the Optional BS350S-W Pedal Wheel Kit
