Rectifier RT9- 24V - User Programmable Relay Functions

Installation, Operation and Technical Manual Rectifier Technologies
158-1872-01 50 19-Feb-14
Alarm Name
Comments
LED
AC Freq Fault
AC frequency lower or higher than preset value
A
Battery Switch
One or more battery switches open
A
Cct Breaker
Fuse or CB in load distribution open
A
LVDS Open
Low Voltage Disconnect switch open
A
Sys Volts High
System output volts too high
A
Sys Volts Low
System output volts too low
A
System V Clamp
MCSU-4 can not reach desired system voltage. This can be due to
possible excessive voltage drop along bus bars or “System V Drop”
parameter has value too low.
A
Cell V High
One or more cells being monitored by BCM is too high in voltage
A
Cell V Low
One or more cells being monitored by BCM is too low in voltage
A
Cell %dev High
One or more cells being monitored by BCM is too high % deviation from
the mean battery cell voltage
A
Cell %dev Low
One or more cells being monitored by BCM is too low % deviation from
the mean battery cell voltage
A
Range SMR
SMR parameter range error. MCSU-4 could not overwrite values
A
Site Monitor
Alarm present from the site monitor module. See site monitor menu for
details of alarm channel.
A
Battery Disch
Batteries are discharging
A
Disch Tst Fail
Battery discharge test failed to reach a programmed end point
A
Bat Disch Low
Alarm flags only if the system voltage falls below Discharge Alarm level
while the battery is discharging
A
Lo Electrolyte
Alarm generated for NiCad batteries using special sensor and software
A
SMR Comms Fail
One or more of SMRs are not responding
A
Amb Temp High
Ambient temperature higher than preset limit
A
Batt Temp High
Battery temperature higher than preset limit
A
Batt Temp Sens
Battery temperature sensor not connected or failure
A
Batt I-Limit
Battery charging current is being limited to preset value
A
Bat Sym Alarm
Battery discharge currents from battery strings not sharing load equally
A
Earth Leak Alarm
Earth leakage current greater than the limit set
A
Equalise
System is in equalise mode
A *
R = red LED on A = amber LED flashing * not flashing
6.4 User programmable relay functions
All controllers with RTP standard software of version/revision ‘fa’ or higher support this
feature. Other customised software can include it as well. To check if your unit supports
programmable relays, perform Indicators Test as described in section 6.6.3.
New units have factory default relay assignment. For details refer to paragraph “Relay
Contact outputs” in User Interface sections of this manual.
