Single phase AC voltage.
1ph AC Volts
245V
Single phase AC current
1ph AC Current
52A
Single phase AC frequency
1ph AC Frequency
50.0Hz
6.6.2 Three Phase AC Monitoring Screens
In a system wired for 3 phase input with an AC monitor module, it will be necessary to
activate the 3 phase AC monitoring selection screen via the “Auxiliary Units” sub-menu
(towards the end of this menu). To enable, select “On” under the “3-ph AC Monitor” menu
item. Once the AC monitor is enabled, the following screens will appear immediately after
the “Ambient Temp” screen or single phase monitoring screens (when activated):
AC voltage of phase 1
3ph AC1 Volts
245V
AC voltage of phase 2
3ph AC2 Volts
243V
AC voltage of phase 3
3ph AC3 Volts
246V
AC Current of phase 1
3ph AC1 Current
28A
AC Current of phase 2
3ph AC2 Current
29A
AC Current of phase 3
3ph AC3 Current
32A
AC Frequency
3ph AC Frequency
50.2Hz
