red lion PAXT0010 User Manual

5
mOdel paXH - aC TrUe rms vOlT and CUrrenT
 FOUR VOLTAGE RANGES (300 VAC Max)
 FIVE CURRENT RANGES (5 A Max)
 ACCEPTS AC OR DC COUPLED INPUTS
 THREE WAY ISOLATION: POWER, INPUT AND OUTPUTS
mOdel paXs - sTrain gage inpUT
 LOAD CELL, PRESSURE AND TORQUE BRIDGE INPUTS
 DUAL RANGE INPUT: ±24 mV OR ±240 mV
 SELECTABLE 5 VDC OR 10 VDC BRIDGE EXCITATION
 PROGRAMMABLE AUTO-ZERO TRACKING
PAXS SPECIFICATIONS
SENSOR INPUTS:
PAXH SPECIFICATIONS
INPUT RANGES:
Isolation To Option Card Commons and User Input Commons: 125 Vrms
Isolation To AC Power Terminals: 250 Vrms
*Conditions for accuracy specification:
- 20 minutes warmup
- 18-28°C temperature range, 10-75% RH non-condensing
- 50 Hz - 400 Hz sine wave input with 1.414 crest factor
- 1% to 100% of range
For conditions outside the above listed:
Temperature from 0-18 and 28-50°C: Add 0.1% reading + 20 counts error
Crest factors:
1-3: Add 0.2% reading + 10 counts error
3-5: Add 1% reading
DC component: Add 0.5% reading + 10 counts
20-50 Hz and 400-10 KHz: Add 1% reading + 20 counts error
** Non-repetitive surge rating: 15 A for 5 seconds
*** Inputs are direct coupled to the input divider and shunts. Input signals with
high DC component levels may reduce the usable range.
MAX CREST FACTOR (Vp/VRMS): 5 @ Full Scale Input
INPUT COUPLING: AC or AC and DC
INPUT CAPACITANCE: 10 pF
COMMON MODE VOLTAGE: 125 VAC working
COMMON MODE REJECTION: (DC to 60 Hz) 100 dB
INPUT
RANGE
ACCURACY*
MAX DC
BLOCKING
IMPEDANCE
(60 Hz)
MAX
CONTINUOUS
OVERLOAD
RESOLUTION
2 mA
0.1% of reading
+2 µA
±50 mA111 ohm 50 mA 0.1 µA
20 mA
0.1% of reading
+20 µA
±150 mA11.1 ohm 150 mA 1 µA
200 mA
0.1% of reading
+0.2 mA
±500 mA1.1 ohm 500 mA 10 µA
5 A
0.5% of reading
+5 mA
±7 A***0.02 ohm 7 A** 1 mA
200 mV
0.1% of reading
+0.4 mV
±10 V686 Kohm 30 V 0.01 mV
2 V
0.1% of reading
+2 mV
±50 V686 Kohm 30 V 0.1 mV
20 V
0.1% of reading
+20 mV
±300 V686 Kohm 300 V 1 mV
300 V
0.2% of reading
+0.3 V
±300 V***686 Kohm 300 V 0.1 V
200 µA
0.1% of reading
+0.4 µA
±15 mA1.11 Kohm 15 mA 0.01 µA
CONNECTION TYPE: 4-wire bridge (differential)
2-wire (single-ended)
COMMON MODE RANGE (w.r.t. input common): 0 to +5 VDC
Rejection: 80 dB (DC to 120 Hz)
BRIDGE EXCITATION :
Jumper Selectable: 5 VDC @ 65 mA max., ±2%
10 VDC @ 125 mA max., ±2%
Temperature coefficient (ratio metric): 20 ppm/°C max.
INPUT RANGE
ACCURACY*
(18 to 28 °C)
ACCURACY*
(0 to 50 °C)
IMPEDANCE
MAX
CONTINUOUS
OVERLOAD
RESOLUTION
±24 mVDC
0.02% of
reading +3 µV
0.07% of
reading +4 µV
100 Mohm 30 V 1 µV
±240 mVDC
0.02% of
reading +30 µV
0.07% of
reading +40 µV
100 Mohm 30 V 10 µV
* After 20 minute warm-up. Accuracy is specified in two ways: Accuracy over an 18
to 28 °C and 10 to 75% RH environment; and accuracy over a 0 to 50 °C and 0 to
85% RH (non-condensing environment). Accuracy over the 0 to 50 °C range
includes the temperature coefficient effect of the meter.
