ASSEMBLY AND FOLDING
ASSEMBLY STEPS
NOTE: THE RUNNING BELT IS MADE OF HEAD AND TAIL SPLICING, THERE ARE
SEAM MARKS, IT IS NORMAL PROCESS PHENOMENON, AND DOES NOT AFFECT THE
NORMAL USE OF THE TREADMILL.
STEP 1
Unpack your package, take out the related
accessories and the machine. Put the
machine on level ground.
STEP 2
Unscrew the adjustment knobs on both
sides of the frame (3 turns recommended),
push up the column tube, keep the hinge of
the main unit corresponding to the slot, and
then tighten the adjustment knobs on both
sides.
STEP 3
Install the safety key to complete the
assembly.
FOLDING STEPS
STEP 1
Hold the column tube with one hand, and
unscrew the adjustment knobs on both
sides of the frame respectively (3 turns
recommended)
STEP 2
Hold the column firmly and lower it until it
lays at. Then screw in the knobs.
STEP 3
The folding of the machine is complete.
